Model

P-1212

P-1325

Travelling Area(X, Y, Z)

1200 x 1200 x 600 mm

1300 x 2500 x 600 mm

Working Area

1200 x 1200 x 500 mm

1300 x 2500 x 500 mm

Transmission

X and Y Axis Transmit by Rack & Pinion with timing pulley & belt mechanism

X and Y Axis Transmit by Rack & Pinion with timing pulley & belt mechanism

Table Structure

Rigid Steel Frame Structure

Rigid Steel Frame Structure

Spindle Power

6 KW, Air Cooled (HSD Italian Spindle)

13.5 KW, Air Cooled (HSD Italian Spindle)

Spindle Speed

18000 RPM

18000 RPM

Maximum Travelling Speed

25 mtr/min

25 mtr/min

Maximum Working Speed

15 mtr/min

15 mtr/min

Driving System

Yaskawa AC Servo Motor 5.39 nm Torque

Yaskawa AC Servo Motor 5.39 nm Torque

Working Voltage

AC 440 /3PH/50hz

AC 440 /3PH/50hz

Command Language

G Code- (*.tab *.NC)

G Code- (*.tab *.NC)

Operating System

NC Studio Software with PCI controller

NC Studio Software with PCI controller
